Guide Complete Ruhle IR56 Injector

Type: F42157
Ships from: FOB Brampton Canada
U/M: Each
Stock: On Order
CM: 1370

* Guide Complete IR 56:

CM Machine Services Ltd. Product Information

To make Purchase Call 905-793-3994 or Email sales@cmmachineservices.net Prices are subject to change without notice.

Guide Complete Ruhle IR56 Injector

Type: F42157
Location: FOB Brampton Canada
U/M: Each
Stock: On Order
CM Product Code: 1370

* Guide Complete IR 56:
--F29240 Traverse
-- F240137 Shaft
--F240138 Bushing
--F20147 Hexagonal nut
--101110 Traverse
--F22888 Washer
--F21260 Spring lock washer
--F20259 Hexagonal nut
--F22138 Hexagonal bolt
--F27693 Washer
-- F26379 Spring lock washer
--F451515 bearing
--F40766 Guide tube
-- F240778 Nut

Guide Complete for Ruhle IR56 Meat Injector

Pos No.	Part No.	Description	Add Info	Required
1	F29240	Traverse	580 x 120 x 10	1
2	F240137	Shaft	Ø 16 x 125	4
3	F240138	Bushing	Ø 22 x 72	4
4	F20147	Hexagonal nut	DIN934 M 10	8
5	101110	Traverse	IR 28/56	1
6	F22888	Washer	DIN125 A 8,4	2
7	F21260	Spring lock washer	DIN127 B 8	2
8	F20259	Hexagonal nut	DIN934 M 8	2
9	F22139	Hexagonal bolt	DIN933 M10 x 25	4
10	F27693	Washer	DIN125 A 10,5	4
11	F26379	Spring lock washer	DIN127 B 10	4
12	F451515	bearing	IR 28/56	2
13	F40766	Guide tube	IR 28/56	2
14	F240778	Nut	M 40 x 1,5 x SW 60 x 6	4

CM Machine Services Ltd. | 55 Stafford Drive Unit "I" | Brampton, On L6W 1L3

PH: 905-793-3994 | Contact: sales@cmmachineservices.net

Description

Guide Complete for Ruhle IR56 Meat Injector

Pos No.	Part No.	Description	Add Info	Required
1	F29240	Traverse	580 x 120 x 10	1
2	F240137	Shaft	Ø 16 x 125	4
3	F240138	Bushing	Ø 22 x 72	4
4	F20147	Hexagonal nut	DIN934 M 10	8
5	101110	Traverse	IR 28/56	1
6	F22888	Washer	DIN125 A 8,4	2
7	F21260	Spring lock washer	DIN127 B 8	2
8	F20259	Hexagonal nut	DIN934 M 8	2
9	F22139	Hexagonal bolt	DIN933 M10 x 25	4
10	F27693	Washer	DIN125 A 10,5	4
11	F26379	Spring lock washer	DIN127 B 10	4
12	F451515	bearing	IR 28/56	2
13	F40766	Guide tube	IR 28/56	2
14	F240778	Nut	M 40 x 1,5 x SW 60 x 6	4
