Verteileinrichtung Exploded view for Ruhle IR56 Injecting
| Pos No. | Part No. | Description | Add Info | Required | |
 |
1 | 105192 | Block | IR 56 | 1 |
 |
2 | F29316 | Support | Ø 25 x Ø 60 x 119 | 1 |
 |
3 | F240240 | O-Ring | Ø 26 x 2 | 1 |
 |
4 | F20264 | Countersunk bolt | DIN963 M 6 x 16 | 4 |
 |
5 | F29310 | Cover | 359,5 x 114,5 x 4 | 1 |
 |
6 | F25965 | Straight Pin | ISO2338 - Ø 6m6 x 20 | 2 |
 |
7 | F29314 | Seals | Ø 3 x 850 | 1 |
 |
8 | F244799 | Cover | 359,5 x 114,5 x 20 | 1 |
 |
9 | F29311 | Cover | 359,6 x 114,6 x 4 | 1 |
 |
10 | F29313 | Bushing | Ø 4,1 x Ø 18 x 12 | 56 |
 |
11 | F29099 | Sleeve Nut | M 6 x 15 | 12 |
 |
12 | F29100 | Screw | DIN964 M 6 x 50 | 12 |
 |
13 | F29312 | Ros Seal | NIPSL 310 blau | 56 |
