Mounting Plate Exploded View Ruhle SR2 Turbo
Type: F41492et
Ships from: FOB Brampton Canada
U/M: Each
Stock: On Order
CM: 691
Ships from: FOB Brampton Canada
U/M: Each
Stock: On Order
CM: 691
Note: Shipping to be Determined.
Mounting Plate Exploded View for Ruhle SR2 Turbo
| Pos No. | Part No. | Description | Add Info | Required | |
 |
1 | F453869 | Mounting plate | SR 2 Turbo | 1 |
 |
2 | F28732 | lock washer | DIN6797-A ø 6,4 | 1 |
 |
3 | F20258 | Washer | DIN125 A 6,4 | 1 |
 |
4 | F24031 | Spring lock washer | DIN127 B 6 | 1 |
 |
5 | F20203 | Hexagonal nut | DIN934 M 6 | 1 |
 |
6 | F27057 | Phase sequence relay | IK 9179 | 1 |
 |
7 | F28956 | Monitoring unit | MÜZ 202/D24-FL | 2 |
 |
8 | F28743 | PLC-Module | S7-200 / CPU 224 | 1 |
 |
9 | F27059 | PLC-Module | S7-200 / EM 222 | 1 |
 |
10 | F28020 | Cable | BT2 operator terminal | 1 |
 |
11 | F27069 | Power supply 400AC/12DC/24DC | 1282-0023-0000 | 1 |
 |
12 | F20723 | Fuse terminal grey | 5.0 x 20mm | 7 |
 |
13 | F27064 | Fuse 3.15 AT | 5.0 x 20mm | 8 |
|
14 | F23890 | Fuse 6.3 AT | 5.0 x 20mm | 6 |
 |
15 | F27065 | Side plate grey | FEM 8S | 1 |
 |
16 | F27066 | Fuse terminal black | 6,4 x 32 mm | 1 |
 |
17 | F28281 | Fuse 20 AT | 6,3 x 32 mm | 2 |
 |
18 | F27067 | Side plate black | FEM 13U | 1 |
 |
19 | F28480 | Power contactor 24VDC | LP1-K0901 BD3 | 2 |
 |
20 | F20916 | Turn contactor | LP2-KO910 BD3 | 3 |
 |
21 | F27091 | Power contactor 24VDC | LP1-K0910 BD3 | 1 |
 |
22 | F41540 | Relay | 1 We / 24 VDC / 10A | 5 |
|
23 | F41539 | Relay | 1 We / 24 VDC / 10A | 1 |
 |
24 | F27072 | Time relay | CT-ARE | 1 |
 |
25 | F27077 | Motor protect relay 5.5-8.0A | LR 2-K0314 | 2 |
 |
26 | F28668 | Motor protect relay 0.36-0.54A | LR 2-K0304 | 1 |
 |
27 | F20911 | Motor protect relay 0.8-1.2A | LR 2-K0306 | 1 |
 |
28 | F27083 | Diode | 1N5401 | 2 |
 |
29 | F28735 | Terminal strip | SR 2 T | 1 |
 |
30 | F28278 | End Terminal | BNK - BADL | 2 |
 |
31 | F148541 | Sticker | BMK02 | 1 |
