Platte Assembly
| Pos. No. | Part No. | Description | Add. Info | Required | ||
|---|---|---|---|---|---|---|
 |
1 | 108177 | Blech | 750 x 300 x 3 | 1 | |
 |
2 | F248399 | Sechskantschweißmutter | DIN929 M 5 | 12 | |
 |
3 | F26699 | Hubzündungsbolzen | M 6 x 12 | 1 | |
 |
4 | F21045 | Washer | DIN125 A 5,3 | 12 | |
 |
5 | F20260 | Spring lock washer | DIN127 B 5 | 12 | |
 |
6 | F22174 | Cylinder head screw | DIN912 M 5 x 12 | 12 | |
 |
7 | F28732 | lock washer | DIN6797-A ø 6,4 | 1 | |
 |
8 | F20258 | Washer | DIN125 A 6,4 | 1 | |
 |
9 | F24031 | Spring lock washer | DIN127 B 6 | 1 | |
 |
10 | F20203 | Hexagonal nut | DIN934 M 6 | 1 | |
 |
11 | 108256 | Frequenzumrichter 5,5kW | MGR 900 | 1 | |
 |
12 | 108258 | Frequenzumrichter 2,2kW | MGR 900 | 1 | |
 |
13 | 108259 | Frequenzumrichter 4,0kW | MGR 900 | 1 | |
 |
14 | F148541 | Sticker | BMK02 | 1 | |
 |
15 | F10131 | Sticker | flash | 1 | |
 |
16 | 108234 | Erdungskabel | MGR 400/900/1500 | 1 |
