Nock Gyros Cutting Cortex CB 496

Type: cutting width: 430mm
Country of Origin: Germany
Ships from: FOB Brampton, ON Canada (O)
U/M: Each
Stock: On Order
CM: 6437
Financing Available
Note: Shipping to be determined
Options for Nock Cortex CB 496 Gyro:



Nock Cortex CB 496 Gyros Cutting Machine

Cutting machine for gyros and doner production with spring suspended pressure unit, infinitely variable in height. This machine has the cutting width of 430mm.

Features and application range:

  1. With infeed conveyor (850x425mm) and output slide sheet
  2. Without discharge conveyor
  3. Blade gap infinitely variable from 0.5-8 mm
  4. Cutting width: 430 mm
  5. Cutting speed: 24 m/min
  6. Max height of meat: 90mm

Technical Data:

cutting width

430 mm

cutting speed

24 mm/min

cutting direction

horizontally

max. throughput height

90 mm

blade gap



0.5 - 8 mm infinitely adjustable
other thicknesses upon request



apply length on infeed conveyor

400 mm

infeed conveyor

850 x 425 mm

discharge conveyor for cut meat slices

850 x 425 mm

overall dimension W x H x D (with Integrated Product Return System)

910 x 1190 x 1210 mm

weight

240 kg

motor performance

0.75 kW

electrical connection



3 AC - 400 V - 50 Hz
IEC 60309 16 A 6h
other voltages upon request



Options:

  • INTEGRATED NOCK PRODUCT RETURN SYSTEM (highly recommended!)
  • Discharge conveyor for the sliced meat (for feeding of huge bins, e.g. meat trolleys)
  • Discharge conveyor for remaining uncut meat (not together with INTEGRATED NOCK PRODUCT RETURN SYSTEM)
  • Multi cut lines
