Pos. No.  |
Part No. |
Description |
Add. Info |
Required |
| |
 |
1 |
F20048 |
Countersunk bolt |
DIN7991 M 6 x 16 |
1 |
| |
 |
2 |
F20192 |
Shaft |
Ø 35 x 237 |
1 |
| |
 |
3 |
F20194 |
Worm wheel |
Z 24 m 4,0 |
1 |
| |
 |
4 |
F20200 |
Flange |
Ø 30,5 x Ø 120 x 35 |
1 |
| |
 |
5 |
F20201 |
Bracket |
198,2 x 88,1 x 30 x 15 |
1 |
| |
 |
6 |
F20202 |
Washer |
DIN125 A 13 |
5 |
| |
 |
7 |
F20203 |
Hexagonal nut |
DIN934 M 6 |
4 |
| |
 |
8 |
F20204 |
Hexagonal nut |
DIN934 M 12 |
5 |
| |
 |
9 |
F20207 |
Countersunk bolt |
DIN7991 M 8 x 25 |
12 |
| |
 |
10 |
F20210 |
Spring lock washer |
DIN127 B 12 |
4 |
| |
 |
11 |
F20211 |
Grooved ball bearing |
DIN625 - 4206 |
1 |
| |
 |
12 |
F20213 |
Tapered ball bearing |
DIN628 - 3204 |
1 |
| |
 |
13 |
F20214 |
Slide bushing |
DIN1850 Ø 15 x Ø 20 x 15 |
1 |
| |
 |
14 |
F20217 |
Locking ring |
DIN471 Ø 30 x 1,5 |
1 |
| |
 |
15 |
F20222 |
Spring key |
A 6 x 6 x 16 |
1 |
| |
 |
16 |
F20223 |
Spring key |
A 8 x 7 x 30 |
1 |
| |
 |
17 |
F20225 |
stud screw |
DIN835 M 8 x 38 |
4 |
| |
 |
18 |
F20227 |
Threaded pin |
DIN914 M 8 x 16 |
1 |
| |
 |
19 |
F20229 |
Hexagonal bolt |
DIN933 M12 x 60 |
2 |
| |
 |
20 |
F20230 |
Hexagonal bolt |
DIN933 M12 x 40 |
2 |
| |
 |
21 |
F20259 |
Hexagonal nut |
DIN934 M 8 |
4 |
| |
 |
22 |
F20208 |
Countersunk bolt |
DIN7991 M 8 x 20 |
1 |
| |
 |
23 |
F21260 |
Spring lock washer |
DIN127 B 8 |
4 |
| |
 |
24 |
F21309 |
Radial shaft seal |
Ø 30 x Ø 40 x 7 |
1 |
| |
 |
25 |
F21345 |
Radial shaft seal |
Ø 35 x Ø 47 x 7 |
1 |
| |
 |
26 |
F22888 |
Washer |
DIN125 A 8,4 |
4 |
| |
 |
27 |
F22943 |
Threaded pin |
DIN551 M 6 x 30 |
4 |
| |
 |
28 |
F24031 |
Spring lock washer |
DIN127 B 6 |
4 |
| |
 |
29 |
F25272 |
bushing |
M 26 x 1,5 x Ø 50 x 15 |
1 |
| |
 |
30 |
F25274 |
Worm |
Ø 24 x Ø 58 x 65 |
1 |
| |
 |
31 |
F26569 |
Grooved ball bearing |
DIN625 - 6203 1Z |
1 |
| |
 |
32 |
F27669 |
bolt |
SW 19 x 53,8 |
1 |
| |
 |
33 |
F27788 |
Tapered ball bearing |
DIN628 - 3201 2RS |
1 |
| |
 |
34 |
F28160 |
Flange |
Ø 35 x Ø 120 x 35 |
1 |
| |
 |
35 |
F28327 |
Disc |
Ø 10,5 x Ø 34,5 x 2,5 |
1 |
| |
 |
36 |
F257892 |
Plate |
170 x 50 x 2.3 |
2 |
| |
 |
37 |
F28643 |
Gear box PR 9/10/15 empty |
304 x 198 x 151,7 |
1 |
| |
 |
38 |
F10002 |
Oil |
BMB 220 graphite additive |
0,4 |
| |
 |
39 |
F10140 |
Low-viscosity grease |
Low-viscosity grease |
1,5 |
| |
 |
40 |
F40029 |
Eccentric tappet |
PR 8 - 20 |
1 |
| |
 |
41 |
F40031 |
Forward feed |
PR 8 - 15 |
1 |
 |
 |
42 |
F40254 |
Impeller pump |
PR 8 - 20 |
1 |
| |
 |
43 |
F41082 |
Lever |
PR 8 - 20 |
1 |
| |
 |
44 |
F20199 |
Capstan nut |
M 22 x 1.5 |
1 |
| |
 |
45 |
F25432 |
Threaded pin |
DIN914 M 6 x 10 |
1 |
| |
 |
46 |
F24901 |
Washer |
Ø 12,5 x Ø 35 x 3 |
1 |
| |
 |
500 |
F20276 |
Gear motor |
LS90ST |
1 |
|
