Mounting Plate Exploded View SR2 Dicer No. 435
| Pos No. | Part No. | Description | Add Info | Required | |
 |
1 | F453869 | Mounting plate | SR 2 Turbo | 1 |
 |
2 | F28732 | lock washer | DIN6797-A ø 6,4 | 1 |
 |
3 | F20258 | Washer | DIN125 A 6,4 | 1 |
 |
4 | F24031 | Spring lock washer | DIN127 B 6 | 1 |
 |
5 | F20203 | Hexagonal nut | DIN934 M 6 | 1 |
 |
6 | F27057 | Phase sequence relay | IK 9179 | 1 |
 |
7 | F28956 | Monitoring unit | MÜZ 202/D24-FL | 2 |
 |
8 | 107442 | Programmed PLC-Modul | Sr2_V2.1 | 1 |
 |
9 | F29048 | PLC-Module | RIO 16I / KE | 1 |
 |
10 | F29049 | PLC-Module | RIO 16O / KE | 1 |
 |
11 | F28233 | PLC-Module | RIO C24-10 | 1 |
 |
12 | F20723 | Fuse terminal grey | 5.0 x 20mm | 7 |
 |
13 | F27064 | Sicherung 3,15 AT | 5,0 x 20 mm | 8 |
|
14 | F236890 | Fuse 6,3 AT | 5,0 x 20 mm | 6 |
 |
15 | F27065 | Side Plate Grey | FEM 8S | 1 |
 |
16 | F145711-F1 | Beschriftung | F1 | 1 |
 |
17 | F145711-F2 | Beschriftung | F2 | 1 |
 |
18 | F145711-F3 | Beschriftung | F3 | 1 |
 |
19 | F145711-F4 | Beschriftung | F4 | 1 |
 |
20 | F145711-F5 | Beschriftung | F5 | 1 |
 |
21 | F145711-F6 | Beschriftung | F6 | 1 |
 |
22 | F145711-F7 | Beschriftung | F7 | 1 |
 |
23 | F145711-F8 | Beschriftung | F8 | 1 |
 |
24 | F27066 | Sicherungsklemme schwarz | 6,4 x 32 mm | 1 |
 |
25 | F28281 | Fuse 20 AT | 6,3 x 32 mm | 2 |
 |
26 | F27067 | Side Plate Black | FEM 13U | 1 |
 |
27 | F28410 | Power supply 230VAC/24VDC | S-60-24 MW | 1 |
 |
28 | F28480 | Power contactor 24VDC | LP1-K0901 BD3 | 2 |
 |
29 | F20916 | turn contactor | LP2-KO910 BD3 | 3 |
 |
30 | F27091 | Power contactor 24VDC | LP1-K0910 BD3 | 1 |
 |
31 | F41540 | Relay | 1 We / 24 VDC / 10A | 6 |
 |
32 | F41539 | Relay | 1 We / 24 VDC / 10A | 1 |
 |
33 | F27072 | Zeitrelais | CT-ARE | 1 |
 |
34 | F27077 | Motor protect. relay 5.5 -8.0A | LR 2-K0314 | 2 |
 |
35 | F28668 | Motor protect relay 0.36-0.54A | LR 2-K0304 | 1 |
 |
36 | F20911 | Motor protect. relay 0.8 -1.2A | LR 2-K0306 | 1 |
 |
37 | F27083 | Diode | 1N5401 | 2 |
 |
38 | F28735 | Klemmleiste | SR 2 T | 1 |
 |
39 | F28278 | End terminal | BNK - BADL | 2 |
 |
40 | F27772 | Cable duct | 60 x 20 x 2000 | 250 |
|
41 | F27772 | Cable duct | 60 x 20 x 2000 | 90 |
|
42 | F27772 | Cable duct | 60 x 20 x 2000 | 180 |
 |
43 | F28731 | Kabelkanal | 80 x 30 x 2000 | 365 |
|
44 | F28731 | Kabelkanal | 80 x 30 x 2000 | 430 |
 |
45 | F148541 | Sticker | BMK02 | 1 |
