Needle Beam Assembly

Type: 107013
Ships from: FOB Brampton Canada
U/M: Each
Stock: On Order
CM Product Code: 1931

* Needle Beam Assembly PR 10:

Ask a question about this product

CM Machine Services Ltd. Product Information

To make Purchase Call 905-793-3994 or Email sales@cmmachineservices.net Prices are subject to change without notice.

Needle Beam Assembly

Type: 107013
Brand: 1037
Location: FOB Brampton Canada
U/M: Each
Stock: On Order
CM Product Code: 1931

* Needle Beam Assembly PR 10:
--F40170 Needle beam
--F457750 Guide
--F41300 Guide
--F21862 Plate
--F20114 Pressure spring
--F21307 Ring
--F27790 Clamping ring
--F20117 Curing needle

Pos. No.	Part No.	Description	Add. Info	Required
1	F40170	Needle beam	PR 10	1
2	F457750	Guide	PR 8 - 15	2
3	F41300	Guide	PR 8 - 30	2
4	F21862	Plate	325 x 70 x 15	1
5	F20114	Pressure spring	d1.8 x De19 x 285	10
6	F21307	Ring	Ø 10,2 x Ø 19 x 2	10
7	F27790	Clamping ring	Ø 14 x Ø 20 x 12	10
8	F20117	Curing needle	Ø 4,0 x 165	10

CM Machine Services Ltd. | 55 Stafford Drive Unit "I" | Brampton, On L6W 1L3

PH: 905-793-3994 | Contact: sales@cmmachineservices.net

Description

Pos. No.	Part No.	Description	Add. Info	Required
1	F40170	Needle beam	PR 10	1
2	F457750	Guide	PR 8 - 15	2
3	F41300	Guide	PR 8 - 30	2
4	F21862	Plate	325 x 70 x 15	1
5	F20114	Pressure spring	d1.8 x De19 x 285	10
6	F21307	Ring	Ø 10,2 x Ø 19 x 2	10
7	F27790	Clamping ring	Ø 14 x Ø 20 x 12	10
8	F20117	Curing needle	Ø 4,0 x 165	10
