Bearing Exploded View - F4515151

Type: F4515151
Ships from: FOB Brampton Canada
U/M: Each
Stock: On Order
CM: 2137

* Bearing Exploded View 1 IR 112:

CM Machine Services Ltd. Product Information

To make Purchase Call 905-793-3994 or Email sales@cmmachineservices.net Prices are subject to change without notice.

Bearing Exploded View - F4515151

Type: F4515151
Location: FOB Brampton Canada
U/M: Each
Stock: On Order
CM Product Code: 2137

* Bearing Exploded View 1 IR 112:
--F29243 Flange
--F27891 O-ring
--F240141 Flange
--F250346 Seal
--F22888 Washer
--F21260 Spring lock washer
--F22621 Cylinder head screw

Bearing Exploded View for IR 112

Pos No.	Part No.	Description	Add info	Required
1	F29243	Flange	40.2x80x81	1
2	F27891	O-ring	40x5	1
3	F240141	Flange	130x100x8	1
4	F250346	Seal	2x241	1
5	F22888	Washer	DIN125A 8.4	4
6	F21260	Spring lock washer	DIN127 B 8	4
7	F22621	Cylinder head screw	DIN912 M 8x25	4

CM Machine Services Ltd. | 55 Stafford Drive Unit "I" | Brampton, On L6W 1L3

PH: 905-793-3994 | Contact: sales@cmmachineservices.net

Description

Bearing Exploded View for IR 112

Pos No.	Part No.	Description	Add info	Required
1	F29243	Flange	40.2x80x81	1
2	F27891	O-ring	40x5	1
3	F240141	Flange	130x100x8	1
4	F250346	Seal	2x241	1
5	F22888	Washer	DIN125A 8.4	4
6	F21260	Spring lock washer	DIN127 B 8	4
7	F22621	Cylinder head screw	DIN912 M 8x25	4
