Switch Unit Exploded View - 1

  Pos. No. Part No.  Description  Add. Info  Required
F250271 1 F250271 Plate / Sheet 133 x 80 x 4 1
F240041 2 F240041 Threaded rod Ø 10 x 217 1
F250280 3 F250280 Shaft Ø 20 x 242 1
F245844 4 F245844 Cylinder head screw DIN912 M 4 x 16 2
F20570 5 F20570 Washer DIN125 A 4,3 2
F20203 6 F20203 Hexagonal nut DIN934 M 6 1
F444874 7 F444874 Mini hub drive MHG 100/50 1
