Drive Exploded View - SR2 Turbo No. 74 and higher - Conveyor belt

Type: F441364ex
Ships from: FOB Brampton Canada
U/M: Each
Stock: On Order
CM: 764

Note: Shipping to be Determined.

* Drive Exploded View SR2 Turbo No. 74 and higher:

CM Machine Services Ltd. Product Information

To make Purchase Call 905-793-3994 or Email sales@cmmachineservices.net Prices are subject to change without notice.

Drive Exploded View - SR2 Turbo No. 74 and higher - Conveyor belt

Type: F441364ex
Location: FOB Brampton Canada
U/M: Each
Stock: On Order
CM Product Code: 764

Note: Shipping to be Determined.

* Drive Exploded View SR2 Turbo No. 74 and higher:
--F26809 Housing
--F23386 Schrägkugellager
--F26811 Ring
--F26814 Take-up ring
--F240658 Ring
--F28057 Radial shaft sea
--F26813 Scheibe
--F240655 Drive Shaft
--F240654 Bushing
--F22915 Spring key

Pos. No.	Part No.	Description	Add. Info	Required
1	F26809	Housing	Ø 120 x 111,5	1
2	F23386	Schrägkugellager	DIN628 - 3207 2RS	2
3	F26811	Ring	Ø 35,5 x Ø 45 x 40,5	1
4	F26814	Take-up ring	Ø 50 x Ø 72 x 20	1
5	F240658	Ring	Ø 18 x Ø 40 x 20	1
6	F28057	Radial shaft seal	Ø 50 x Ø 65 x 8	2
7	F26813	Scheibe	Ø 55 x Ø 71 x 2	1
8	F240655	Drive Shaft	Ø 50 x 350	1
9	F240654	Bushing	Ø 80 x 267	1
10	F22915	Spring key	A 6 x 6 x 40	1
