Industrial equipment expertise you can rely on.
The heavy-duty Nock Open Top Derinding Machine Cortex C 660/860 series represents a major benchmark in industrial manual skinning, engineered specifically for flexible processing across busy meat rooms, processing plants, and commercial butcher spaces. While often integrated alongside multi-stage automatic derinding machines, this open-top configuration features specialized, highly versatile exchangeable processing tables. Built by Nock, a premier brand recognized globally for manufacturing reliable, long-life food processing derinders, the Cortex C 660/860 series delivers smooth rind separation, absolute structural safety, and maximized product yield when processing demanding, bone-in cuts such as primal hams, heavy shoulders, and bone-in loins.
Engineered specifically for heavy manual skinning lines that handle high or round cuts with bones. Operators can transition the machine footprint instantly by swapping specialized structural tables to perfectly process bone-in hams, shoulders, or loins.
| Technical Parameter | Cortex C 660 | Cortex C 860 |
|---|---|---|
| Operational Cutting Width | 600 mm | 800 mm |
| Linear Cutting Speed | 19 meters per minute | 19 meters per minute |
| Blade Gap Range | 0 - 4.5 mm | 0 - 4.5 mm |
| Motor Performance Rating | 0.75 kW | 0.75 kW |
| Electrical Network Connection | 400V / 50Hz / 3Ph | 400V / 50Hz / 3Ph |
| Overall Dimensions (W x H x D) | 950 mm x 960 mm x 700 mm | 1100 mm x 960 mm x 700 mm |
| Equipment Structural Weight | 180 kg (approx. 396.8 lbs) | 200 kg (approx. 440.9 lbs) |
* Note: Alternative voltage grid configurations are available on factory order request. The high-rigidity structural casing allows for rapid washdown cleaning cycles while ensuring long-term mechanical precision under heavy production demands.
