Traverse Complete 3 - Needle beam
| Pos. No. | Part No. | Description | Add. Info | Required | |
|---|---|---|---|---|---|
 |
1 | 104568 | Traverse | IR 112 | 1 |
 |
2 | F250332 | Shaft | Ø 35 x 95 | 4 |
 |
3 | F250334 | Plate / Sheet | 85,2 x 79,5 x 4 | 4 |
 |
4 | F26897 | Hexagonal nut | DIN439 M 20 x 1,5 | 8 |
 |
5 | F23691 | Grooved ball bearing | DIN625 - 6005 2RS | 8 |
 |
6 | F250333 | Rolle | Ø 27 x Ø 80 x 35 | 4 |
 |
7 | F26862 | Disc | Ø 25,2 x Ø 35 x 3 | 4 |
 |
8 | F25429 | Locking ring | DIN471 Ø 25 x 1,2 | 4 |
 |
9 | F249967 | Plate / Sheet | 140 x 30 x 5 | 2 |
 |
10 | F20210 | Spring lock washer | DIN127 B 12 | 4 |
 |
11 | F20230 | Hexagonal bolt | DIN933 M12 x 40 | 4 |
 |
12 | F20692 | Hexagonal bolt | DIN933 M12 x 50 | 1 |
|
13 | F20204 | Hexagonal nut | DIN934 M 12 | 3 |
