Nock Circular Blade Cutting Cortex CB 598 Jerky Slicer

Type: cutting width: 380mm
Country of Origin: Germany
Ships from: FOB Brampton, ON Canada (O)
U/M: Each
Stock: On Order
Shipping Dimension: 91 X 48 X 63
Shipping Weight: 913 lbs
CM: 8117
Financing Available
Note: Shipping to be determined
* Power Options for Cortex CB 598:

* Required Product Thickness in mm:

Options for Cortex CB 598:







* Electrical Certification:

Nock Cortex CB 598 Jerky Slicer Circular blade cutting machine

Special cutting geometry to slice thin slices from fresh meat pieces, for products such as beef jerky, pork jerky, biltong, milanesa, escalope’s, roulades, etc.

Features:

  • Blade distance is interchangeable in steps / adjustable.
  • Minimum blade distance is from 6 mm
  • Slice thickness from approximately 5.5 mm (depending on the product)

Standard:

  • Infeed conveyor
  • Discharge conveyor
  • Intersection roller with quick change technique
  • NOCK POWER PLATES for the NOCK typical service friendliness
  • NOCK EASY-FLOW safety cover with gas springs for optimal operational safety
  • Lift out device for the blade shaft
  • Blade protective covering
  • Lockable castors
  • Stainless steel

Technical Specifications:

  • Blade diameter: 300mm
  • Max. throughput height: 120mm
  • Blade equipment: max. 380mm
  • Max. throughput width: 475mm
  • Conveyor speed: 18m/min
  • Min. blade distance (tech. limit): 6mm (depending on product)
  • Available blade distance grids: 6-7-8-9-10-11mm
  • Overall dimension: 820x1300x2450mm (WxHxD)
  • Weight: 330kg (with 7mm blade distance)
  • Motor performance: 1.1kW
  • Voltage: 400V 50Hz 3Ph (other voltage options available)

Options:

  • Adjustable guidance rails on infeed conveyor
  • Transport and storage box for the blade shaft
  • Cleaning wagon for 2 blade shafts
  • Intersection roller without quick change system, but with scraper comb
  • Longer conveyors
  • Scraper on the discharge conveyor
